Machine-data
| Stock no. | 1073-7846 |
| Category | Decoilers for Coils |
| Make | DREHER |
| Type | 2380 F-FPS |
| Year | 1994/2010 |
| Control | conventional |
| Storage location | EXW- ex works |
| Origin | Germany |
| Delivery time | immediately |
| Quotation | EXW- ex works (free on Truck) |
| Price | |
Technical details
| sheet width - max. | 0800 mm |
| coil weight | 3,50 t |
| coil internal dia. | 460 -530 mm |
| coil-outside of decoiler | 1400 mm |
| total power requirement | 2,2 kW |
| weight of the machine ca. | 1,95 t |
| dimensions of the machine ca. | 1,60 x 2,20 x 2,60 m |
with hydraulic auxiliary drive, pneumatic lag brake, hydraulic centralized expansion, hydraulic snubber roll
As is, without commissioning / without further work,
Design as described in the technical data sheet
Documents
no documents available
